Product description ※Please note that product information is not in full comprehensive meaning because of the machine translation.
Specifications
WAN interface
Interface : 1000BASE-T/100BASE-TX (supports Auto MDI/MDI-X) x 1
Transmission speed : 1Gbps/100Mbps full-duplex / half-duplex
LAN interface
Interface : 1000BASE-T/100BASE-TX (supports Auto MDI/MDI-X) switching HUB x 4
Transmission speed : 1Gbps/100Mbps full-duplex / half-duplex
Wireless LAN interface
Interface : Wireless LAN Standard Draft IEEE802.11ax/IEEE802.11ax/IEEE802.11ac/IEEE802.11n/IEEE802.11a/IEEE802.11g/IEEE802.11b
Human interface : Wireless LAN Standard Draft IEEE ax / IEEE ac / IEEE n / IEEE a / IEEE g / IEEE b
Human interface : Status indicator lamp x 11 SET button x 1 RESET button x 1 RT/BR/MA mode selector switch x 1 maintenance button x 1
Protocol used : TCP/IP protocol
Power source : AC100VC ± 10% 50/60Hz (AC adapter)
Operating Environment : Temperature 0 to 40 ℃ Humidity 10 to 90% (non-condensing)
External Dimensions (W x D x H) : approx. 46.5 x 180 x 180 mm
Mass : approx. 0.6 kg
